Magnetek 1X00024H01 WH1-2FF power module

Brand:Magnetek
Model:1X00024H01 WH1-2FF
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Magnetek 1X00024H01 WH1-2FF power module

Product manual:

1、 Product Overview
Magnetek 1X00024H01 is an industrial grade power module, typically labeled as WH1-2FF, primarily used in Emerson/Westinghouse's Ovation distributed control system (DCS).

Main technical parameters:

Input voltage: 100-240 VAC, 50/60 Hz

Input current: approximately 8-12 A (depending on input voltage)

Output voltage: 24   VDC

Output power: up to approximately 500   W

Application type: AC to DC stabilized power module

2、 Application Fields
Power plant control system

Widely used as the main control power supply for Ovation control systems in thermal, hydroelectric, nuclear and other power plants.

Provide 24V stable DC output to ensure long-term stable operation of control modules and I/O modules.

Water Treatment and Environmental Protection Engineering

In sewage treatment plants and water treatment plants, power is supplied to the signal conditioning module and actuator in the process control system.

Adapt to the long-term uninterrupted operation requirements of industrial sites.

industrial automation control system

Applied to large-scale DCS control systems, providing isolated power supply for process monitoring units, communication modules, and logic boards.

Ensure the continuity and reliability of process data collection and control logic.

Petrochemical, steel and heavy industry

In industries with complex processes and high environmental requirements, provide clean and stable power supply guarantees for key control nodes.

Maintenance and spare parts replacement market

Although it is a discontinued model, it is still used as an important replacement component in equipment refurbishment and old system maintenance due to its widespread use in in-service systems.

3、 Product Features
Stable voltage output, suitable for powering critical control modules

High reliability design, supporting industrial grade continuous operation

Compact structure, convenient for system integration and modular replacement

Equipped with overcurrent and overvoltage protection functions to improve the safety of equipment operation
