MAGNETEK 46S02272-0010 control board

Brand:Magnetek
Model:46S02272-0010
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

MAGNETEK 46S02272-0010 control board

Product manual:

product overview
46S02272-0010 is a control or testing circuit board used by Magnetek in DC drive systems, mainly responsible for signal acquisition and processing, assisting in fault diagnosis and operation monitoring of the drive.

major function
Collect working signals such as internal current and voltage of the driver

Support fault diagnosis and system debugging

Coordinate with the main control board to ensure stable operation of the equipment

scope of application
Commonly used in Magnetek's DC drive series, such as Saber 3306, 3412 and other model drive systems.

precautions
This control board belongs to industrial equipment accessories, and installation and debugging should be completed by professionals
