MAGNETEK CDBR-4220D brake system

Product manual:

MAGNETEK CDBR-4220D brake system
1、 Product Overview
Product type: Dynamic Braking Unit

Input voltage range: DC 510-680V

Rated current: 80A

Rated power: approximately 60kW (approximately 80 horsepower)

Control method: adopting high-performance IGBT switch control technology

Response time: Fast response, usually ≤ 5 milliseconds

Protection level: IP65, with dustproof and waterproof performance

Cooling method: Natural heat dissipation, no need for additional fans

Compact size, easy to install and integrate with the system

2、 Main functions and advantages
Quickly and effectively consume the regenerative energy generated during motor braking, avoiding system protection actions caused by increased DC bus voltage

Convert excess energy into thermal energy and release it through braking resistors to protect the safety of variable frequency drives and motors

Capable of rapid response and adapting to high-frequency braking scenarios such as cranes and automation equipment

Support communication with the main control system of the frequency converter for easy monitoring and diagnosis

The structural design is sturdy and durable, suitable for complex industrial environments

3、 Typical application areas
Cranes and lifting equipment ensure braking safety and system stability

Energy management for frequent start stop equipment in automated production lines

Elevator and lifting platform, control motor regeneration energy to prevent overvoltage

Other industrial machinery that require efficient dynamic braking
