Magnetek CIMR-AU4A0088AAA AC Driver

Product manual:

product overview
CIMR-AU4A0088AAA is an AC variable frequency drive jointly launched by Magnetek and Yaskawa
（AC Inverter Drive）， Widely used in the field of industrial automation control for speed regulation, energy conservation, and process control.

Technical Parameter
Brand/Series: Magnetek/Yaskawa A1000 Series

Model: CIMR-AU4A0088AAA

Rated output current: 88 A

Applicable motor power: 30 kW (approximately 40 HP)

Input voltage: three-phase 380-480 VAC ± 10%

Output frequency range: 0.01-400 Hz

Control method:

V/f control

Vector control (sensorless)

Closed loop vector control (with encoder)

Communication interface: built-in Modbus; Optional Profibus DP, DeviceNet, EtherNet/IP, MECHATROLINK, etc

Cooling method: air cooling

Protection level: IP20 (standard)

Application scenarios
Lifting and Material Handling System
Suitable for high starting torque and high-speed stability applications such as bridge cranes, elevators, and belt conveyor systems.

Pump and fan control
Used for central air conditioning systems, water treatment, and ventilation systems to achieve energy-saving operation and soft start control.

Numerical Control Machine Tools and Processing Equipment
Provide high response and high-precision motor control for dynamic control processes such as cutting, feeding, and positioning.

Elevator and Vertical Conveyor System
Supporting closed-loop control, it can achieve smooth start stop and constant speed operation, improving ride comfort.

Automatic production line
Execute high-frequency start stop control as the main drive or auxiliary shaft drive unit in continuous or intermittent automatic lines.

Product advantages
High performance vector control: capable of outputting rated torque even under low-speed conditions, supporting precise positioning

Powerful communication capability: can be connected to various industrial buses through optional modules, achieving seamless integration with PLC/HMI systems

Product details picture:

CIMR-AU4A0088AAA
