MAGNETEK CIMR-F7U45P5 Adjustable Frequency Driver

Product manual:

MAGNETEK CIMR-F7U45P5 Adjustable Frequency Driver
1、 Product Overview
CIMR-F7U45P5 belongs to the Mitsubishi F7 series variable frequency drive, represented or sold by Magnetek, specifically designed for medium power industrial motor speed regulation. This driver is suitable for various application scenarios, supports high-performance vector control, and can provide stable and efficient speed and torque control.

2、 Technical specifications
Rated power: approximately 45 kW (approximately 60 HP)

Input voltage: three-phase 380-480 VAC

Output frequency range: 0.1 Hz to 400 Hz

Control methods: Sensorless Vector Control and V/f Control

Overload capacity: 150% rated current, lasting for 1 minute

Cooling method: forced air cooling

3、 Product Features
High performance vector control

Realize precise torque and speed control without encoder

Suitable for high dynamic response scenarios

Multiple control modes

Support V/f control and sensorless vector control to meet different load requirements

Comprehensive protection function

Built in multiple protections for overload, overvoltage, undervoltage, overheating, short circuit, etc

Automatic fault diagnosis for easy maintenance

Rich interfaces

Multi channel digital/analog input/output, flexible configuration of control logic

Supports multiple industrial communication protocols (optional modules)

Easy to debug and maintain

Provide a digital operation panel with intuitive and convenient parameter settings

Support parameter storage and fast replication

Product details picture:

CIMR-F7U45P5
