MAGNETEK EDB4034EH dynamic braking resistor

Brand:Magnetek
Model:EDB4034EH
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

MAGNETEK EDB4034EH dynamic braking resistor

Product manual:

1、 Product Overview
MAGNETEK EDB4034EH is a dynamic braking resistor used in AC frequency converter (VFD) systems. It is mainly used to absorb feedback energy during motor deceleration or braking, prevent bus voltage rise, and protect the stable operation of the VFD and the entire drive system. This model is suitable for industrial applications with higher power levels and higher load braking frequencies.

2、 Product Features
High heat capacity design

It can withstand the large amount of regenerative energy generated by frequent braking, has excellent heat dissipation capacity and thermal capacity, and is suitable for heavy-duty and high inertia working conditions.

High resistance matching with precision

Accurately match resistance and power based on driver parameters to ensure sensitive response during system braking and avoid overvoltage tripping or misoperation.

Durable and sturdy structure

The metal shell has good sealing, strong resistance to vibration and corrosion, adapts to harsh industrial environments, and ensures long-term stable operation.

Easy and flexible installation

Support standardized fixed methods, which can be built-in control cabinets or independently installed externally, facilitating system integration and maintenance.

High security protection

Internally, high-temperature resistant and flame-retardant materials are used, with overheat protection characteristics to avoid safety hazards caused by overload or malfunction.

Strong compatibility

It can be perfectly matched with various series of frequency converters from MAGNETEK, such as G+, IMPULSE, VFD series, and is also compatible with most industrial VFD brands.

Energy saving and efficient

Dynamically absorbing feedback energy, avoiding recoil pressure on the frequency converter, improving system energy efficiency and electrical stability.

Suitable for frequent start stop systems

The design is suitable for high-frequency starting, deceleration, and reverse situations, such as lifting, elevators, transmission lines, mechanical processing, and other fields.
