Magnetek GPD505V-B034 inverter

Brand:Magnetek
Model:GPD505V-B034
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Magnetek GPD505V-B034 inverter

Product manual:

1、 Product Overview
Magnetek GPD505V-B034 is a three-phase AC inverter in the GPD 505V series, suitable for industrial drive applications at 460V voltage level, with an output power of 34 HP (horsepower).

2、 Technical specifications (typical)
Input voltage: three-phase 380~460 VAC, 50/60 Hz

Output voltage: 0~460 VAC, variable frequency output

Power level: 34 HP (approximately 25.3 kW)

Output frequency range: 0.1~400 Hz

Control mode: V/f (voltage/frequency) control or vector control

Overload capacity: 150% rated current, lasting for 60 seconds

Cooling method: forced air cooling

Communication interface: Supports expansion cards (such as RS-485, DeviceNet, etc.)

3、 Main product features
1. Advanced vector control technology
Realize precise control of motor torque and speed, especially suitable for high dynamic response scenarios.

Provide sensorless vector control to achieve stable torque output without the need for an encoder.

2. Wide frequency output range
The output frequency can reach 400 Hz, suitable for high-speed motors and special application requirements.

3. Rich protection functions
Built in fault detection and protection mechanisms for overvoltage, undervoltage, overcurrent, overheating, and ground short circuit.

Automatic reset and programmable fault response mechanisms can improve system availability.

4. Easy to set up and debug
Provide a digital operation panel that supports parameter viewing, modification, and storage.

The parameter structure is clear, with quick copying function, suitable for batch debugging.

5. Flexible I/O configuration
Up to 5 digital inputs, 2 analog inputs, 2 relay outputs, and 1 analog output.

All I/O can be functionally mapped through parameters to achieve customized control logic.

6. Built in energy-saving operation mode
Automatically reduce output voltage during light load to lower energy consumption.

Support jumping frequency band (avoiding resonance) and dynamic braking control.
