MAGNETEK L30344 power module

Product manual:

MAGNETEK L30344 power module
1、 Product Overview
Model: L30344 (sometimes corresponding to label 119-8125-00)

Type: High power DC power module

Suitable for various scenarios such as industrial control, power systems, and communication equipment

2、 Main technical parameters
Input voltage: three-phase AC, 380V to 460V, 50/60Hz

Output voltage range: 3.4V DC to 10.5V DC (adjustable)

Output current: up to approximately 500 amperes (depending on voltage setting)

Cooling method: natural air cooling or forced air cooling, depending on the usage environment

Size: Standard rack installation size, suitable for integration into control cabinets or rack systems

3、 Core functions and features
Provides high power output of up to 1750 watts, suitable for powering high-power devices

Wide output voltage range to meet the voltage requirements of different devices

Capable of high current output, suitable for high-power load applications

Modular design that supports parallel use, enhances system capacity and redundancy

Built in multiple protection mechanisms (overvoltage, overcurrent, short circuit, etc.) to ensure equipment safety

Compatible with multiple industrial control systems, with a wide range of applications

4、 Typical application scenarios
Industrial automation systems (PLC, I/O modules, sensors, etc.)

Communication equipment (base stations, switches, etc.)

Power system (relay protection, power control equipment)

Laboratory testing equipment

Redundant power supply system to enhance the reliability of power supply for critical equipment

Product details picture:

L30344
