MAS PD5010-LCD interface module

Brand:MAS
Model:PD5010-LCD
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

MAS PD5010-LCD interface module

Product manual:

The MAS PD5010-LCD interface module is a communication and status interface module that integrates display functions, typically used in industrial automation, power monitoring, or process control systems. The following is a detailed introduction to the module:

1、 Product Overview:
Product model: PD5010-LCD

Brand: MAS (possibly an abbreviation for Monitoring and Automation Systems)

Type: LCD display interface module/communication terminal

Main functions: status display, data communication, system diagnostic interface

2、 Main functions and features:
Functional category description
The LCD screen is equipped with an LCD display, allowing users to view device status, address, operating parameters, fault codes, and other information.
The communication interface supports common communication protocols such as RS-232, RS-485, Modbus RTU, and is used for communication with the main station or upper system.
Built in buttons or touch areas for human-computer interaction, allowing for simple local parameter settings or query operations.
The module address setting can be manually or through software to set the communication address, suitable for multi slave systems.
Diagnosis and monitoring provide visual feedback on system operation, abnormalities, communication status, etc., making it easy for operation and maintenance personnel to troubleshoot problems.

3、 Typical technical parameters (depending on version):
Working voltage: 24V DC (or depending on specific model)

Interface type: RS-485/RS-232, optional Ethernet (some models)

Communication protocol: Modbus RTU, ASCII or custom protocol

Display format: Segmented LCD or graphic LCD (with multiple rows as the main display)

Protection level: generally IP20~IP40 (for use inside cabinets)

Working environment: -10 ° C~+55 ° C, suitable for industrial site use
