METSO D201138L Digital Input/Output Module

Brand:METSO
Model:D201138L
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

METSO D201138L Digital Input/Output Module

Product manual:

Model: METSO D201138L
Type: Digital Input/Output Module
Brand: METSO (now part of Valmet, formerly METSO Automation)
System Platform: Used for Metso DNA DCS Control System

1、 Product Introduction:
D201138L is an integrated digital input/output module used in Metso DNA distributed control system.
This module integrates multiple digital input and output channels into one unit, suitable for situations with limited space or moderate requirements for input and output quantity.

2、 Main functions and features:
Integrated digital input (DI) and digital output (DO) channels

Usually equipped with 8 DI channels and 8 DO channels (the specific number of channels depends on the system configuration)

Input detection of external dry contact signals, switch values, etc

Output control relays, solenoid valves, indicator lights and other load devices

All channels have optoelectronic isolation to improve anti-interference ability

Capable of fault detection and diagnosis

Support hot swapping and modular replacement, easy to maintain

3、 Technical parameters (typical values):
Project parameter description
Number of input channels: 8 channels for digital input
Number of output channels: 8 channels for digital output
Input signal type: dry contact or 24V DC level signal
Output Type 24V DC Source Type Output
Electrical isolation channel for system bus electrical isolation
Working voltage 24V DC (powered by the system motherboard)
The communication interface and controller communicate through the system bus
Installation method: modular insertion installation or DIN rail
Working temperature -20 ° C to+60 ° C (industrial grade environment)

4、 Typical applications:
Switching input acquisition and output control in control systems

Status acquisition and remote control of automation equipment in power plants

Process flow switch control, interlock logic execution

Widely used in process control systems for industries such as power, petrochemicals, pulp and paper, water treatment, etc
