MOOG D633-317B power servo valve

Brand: Extreme Networks
Model:D633-317B
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

MOOG D633-317B power servo valve

Product manual:

MOOG D633-317B Power Servo Valve Description
1、 Overall Overview

MOOG D633-317B is a D633 series high-performance power servo valve widely used in industrial automation, machine tool control, testing platforms, and aviation hydraulic systems.
It can accurately convert input electrical signals into hydraulic flow or pressure outputs for controlling the force, position, or speed of actuators, achieving high-precision and high dynamic response hydraulic control.

2、 Main characteristics

Control type: power servo valve, used for precise driving of hydraulic actuators

Control method: electro-hydraulic control, regulating flow rate through DC electrical signals

Valve port type: four port three position structure, supporting bidirectional hydraulic control

Response speed: High dynamic response, suitable for high-speed control systems

Linear characteristics: The output flow rate is highly linear with the input signal, ensuring control accuracy

Repeatability: High repeatability accuracy ensures stable actuator action

Electrical interface: Standard ± 10V or ± 12V signal input, depending on system design

3、 Functional Features

high-precision control
D633-317B can achieve precise flow and pressure regulation, meeting the requirements of high demand hydraulic control systems.

quick response
Valve body structure optimization ensures fast response under high dynamic loads, reducing hysteresis and overshoot.

durable and reliable
The valve body and internal components are made of high-precision machining and wear-resistant materials, suitable for long-term industrial environment use.

wide applicability
Can be used in hydraulic control scenarios such as robotic arms, flight control systems, industrial automation, and testing platforms.

Easy debugging
Support regulating valve operating characteristics through electrical signals, facilitating system integration and performance optimization.

4、 Applicable scenarios

Aviation Flight Control System

Industrial automation hydraulic control

Precision machine tool servo hydraulic system

Testing and simulation platform

High dynamic load precision control system
