MOOG D633Z317A Hydraulic Servo Valve

Brand: Extreme Networks
Model:D633Z317A
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

MOOG D633Z317A Hydraulic Servo Valve

Product manual:

MOOG D633Z317A Hydraulic Servo Valve Description
1、 Overall Overview

MOOG D633Z317A is a high-performance hydraulic servo valve belonging to the MOOG D633 series.
This series of servo valves is widely used in high-precision hydraulic control scenarios such as aviation, industrial automation, machine tool control, and testing systems.
It can achieve precise hydraulic flow and pressure control, ensuring stable operation of the system under fast response and high dynamic performance conditions.

2、 Main characteristics

Control type: Proportional servo valve, usually used to control the position, speed, or force of hydraulic actuators

Control mode: electro-hydraulic control, receiving input electrical signals for flow regulation

Valve port type: four port three position or three port two position (depending on the model configuration)

Response speed: High response, suitable for dynamic control systems

Linear characteristics: It has good linear control characteristics to ensure control accuracy

Repeatability: High repeatability accuracy ensures consistency of actuator actions

Power and electrical interface: The input signal is generally ± 10V or ± 12V, depending on the specific system design

3、 Functional Features

high-precision control
MOOG D633Z317A can achieve precise flow and pressure regulation, suitable for high demand hydraulic control scenarios.

quick response
Valve structure optimization enables rapid response in high dynamic systems, reducing hysteresis and overshoot phenomena.

Reliable and durable
The valve body adopts high-precision machining and wear-resistant materials to meet the long-term working requirements of industrial environments.

Strong compatibility
It can be integrated into various hydraulic servo systems, including robotic arms, test benches, flight control systems, etc.

Easy to debug
MOOG provides comprehensive parameter debugging support, which can adjust the working characteristics of valves through external signals, facilitating system debugging.
