Moog D682Z4743F proportional valve

Brand: Extreme Networks
Model:D682Z4743F
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

MOOG D682Z4743F proportional valve

Product manual:

Moog D682Z4743F Proportional Valve Description
1、 Overall Overview

Moog D682Z4743F is a high-performance hydraulic proportional valve belonging to the Moog D682 series.
This series of proportional valves is widely used in high-precision hydraulic control systems such as aviation, industrial automation, machine tool control, and testing platforms.
It can accurately convert input electrical signals into hydraulic flow or pressure outputs, achieving precise power control and dynamic response.

2、 Main characteristics

Control type: Proportional valve, used to control the position, speed, or force of hydraulic actuators

Control mode: electro-hydraulic control, receiving DC voltage signals to achieve flow regulation

Valve port type: usually a four port three position structure, supporting bidirectional hydraulic control

Response speed: High dynamic response, suitable for fast control systems

Linear characteristics: Control the output and input signals to be highly linear, ensuring precise control

Repeatability: High repeatability accuracy ensures stable and consistent actuator actions

Electrical interface: Standard DC input signal ± 10V or ± 12V, depending on system configuration

3、 Functional Features

high-precision control
D682Z4743F can achieve precise flow or pressure regulation, meeting high demand hydraulic control tasks.

quick response
Valve design optimization with fast response capability to maintain stable control under high dynamic loads.

durable and reliable
The valve body and internal components are made of high-precision machining and wear-resistant materials, suitable for long-term industrial environment use.

wide applicability
Can be used for various hydraulic systems, including robotic arms, test benches, flight control systems, and industrial automation platforms.

Easy to debug and integrate
Support regulating the working characteristics of valves through electrical signals, facilitating system integration and parameter debugging.
