Moog G631 servo valve

Brand: Extreme Networks
Model:G631
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

MOOG G631 servo valve

Product manual:

Moog G631 servo valve description
1、 Overall Overview

The Moog G631 series servo valve is a high-performance proportional servo valve widely used in high-precision hydraulic systems such as aviation, industrial automation, machine tool control, and testing platforms.
This series of servo valves can accurately convert electrical signals into hydraulic flow or pressure outputs, achieving precise position, speed, or force control of actuators and meeting high dynamic and high-precision control requirements.

2、 Main characteristics

Control type: Proportional servo valve, used for precise control of hydraulic actuators

Control mode: electro-hydraulic control, input DC electrical signal to adjust hydraulic flow rate

Valve port type: four port three position or three port two position, supporting bidirectional hydraulic control

Response speed: High dynamic response, suitable for fast control systems

Linear characteristics: The output flow rate is highly linear with the input signal, ensuring precise control

Repeatability: High repeatability accuracy ensures stable actuator action

Electrical interface: Standard ± 10V or ± 12V signal input, depending on system configuration

3、 Functional Features

high-precision control
Capable of achieving precise flow and pressure regulation to meet the control tasks of high demand hydraulic systems.

quick response
Optimization of valve body structure enables rapid response in high dynamic systems, reducing hysteresis and overshoot.

durable and reliable
The valve body and internal components are made of high-precision machining and wear-resistant materials, suitable for long-term industrial environment use.

wide applicability
Can be used for hydraulic systems such as robotic arms, flight control, testing platforms, and industrial automation.

Easy to debug
Support regulating valve operating characteristics through electrical signals, facilitating system integration and performance optimization.
