Motorola MVME162-02 Industrial Control Card

Product manual:

1、 Product Overview

The Motorola MVME162-02 is a VMEbus industrial control card based on the MC68040/MC68030 processor, which is an early model of the MVME162 series of single board computers. This module integrates resources such as processor, memory, timer, serial/parallel interface, etc., and can be used as an independent control unit or core processing module of distributed systems in industrial automation, communication, transportation, power, and military aviation systems.

It has the characteristics of compact design, rich I/O interfaces, and strong real-time processing capability, making it a classic embedded control card for many industrial applications.

2、 Technical parameters

Processor: Motorola MC68030 CPU (25 MHz, some versions can support MC68LC040/MC68040 upgrade)

Coprocessor: MC68882 Math Coprocessor (optional, used to accelerate floating-point operations)

Memory:

DRAM: 4 MB -16 MB (expandable)

EPROM/Flash: 256 KB -2 MB (stores boot code and firmware)

NVRAM: With real-time clock function, used for saving system parameters

Bus interface:

Compliant with ANSI/IEEE VMEbus standards

Support A16/A24/A32 address space

Data width D08/D16/D32

I/O interface:

4-channel serial port (RS-232/RS-422 configurable)

1 parallel I/O channel

watchdog

Real time clock (RTC)

Debugging and system support:

Built in self-test function (BIT)

Support VME interrupts and DMA

Compatible with real-time operating systems such as VxWorks, pSOS, UNIX, etc

3、 Application scenarios

Industrial Automation and Process Control

As the core processing unit of DCS/PLC, it performs factory production process monitoring and logic control.

Transportation and Railway Signal System

Applied to signal control, vehicle scheduling, and safety protection systems.

Electricity and Energy Management

Used for substation automation, generator control, and energy data collection.

Communication and network equipment

As the control core of telecommunications switches and network node equipment.

Military and Aerospace Industry

Suitable for flight control systems, radar control, simulation and training equipment.

Motorola MVME162-02 Product details picture:

MVME162-02

Motorola MVME162-02 product video
