Motorola MVME162PA-252SE Digital Input Card

Product manual:

Product Overview

Motorola MVME2304 01-W3345F is a version of the MVME2300 series Single Board Computer (SBC), based on the PowerPC architecture processor and designed specifically for VME bus systems.
As the core control and data processing unit of the system, it can simultaneously undertake logic control, signal processing, and pulse control functions, and is therefore referred to as the "control pulse card" in some industry documents.

Technical parameters (typical configuration, refer to MVME2300 series)

Processor: Motorola PowerPC 603/604 series, with a clock frequency range of approximately 200MHz~300MHz.

Cache: Built in L1 instruction/data cache, some models support external L2 cache.

System memory: Supports DRAM (usually 32MB~256MB, expandable), with Flash/EPROM for firmware and boot.

Bus interface: compatible with VME64 standard and can be used as a system controller.

I/O interface:

Serial interface (RS-232/RS-422)

Ethernet interface (10/100Mbps)

SCSI interface (commonly found in this series)

Universal timing/pulse interface for external device synchronization and control

Operating system support: real-time operating systems such as VxWorks, Lynx OS, pSOS, etc.

Power supply: Powered through the VME backplane (+5V/± 12V).

Application scenarios

Industrial control: As the core processing and pulse control board for automated production lines and CNC equipment.

Telecommunications and Networks: deployed in communication switches, signal processing, and base station equipment.

Military and Aviation Electronics: Used for real-time control, signal acquisition, and command systems.

Traffic control: used in railway and subway signal systems to control pulses and logical operations.

Testing and Measurement: As the core board for data acquisition and device synchronization.

Product advantages

High performance processing capability: Based on PowerPC architecture, suitable for real-time task processing.

Rich interfaces: serial port, Ethernet, SCSI, and pulse control interfaces, making it easy to integrate in multiple types of systems.

Modular design: other functional modules can be flexibly combined within the VME framework.

Motorola MVME162PA-252SE Product details picture:
