Motorola MVME172-263 01-W3183F-10A Digital Control Board

Brand:Motorola
Model:MVME172-263 01-W3183F-10A
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Motorola MVME172-263 01-W3183F-10A Digital Control Board

Product manual:

Motorola MVME172-263 01-W3183F-10A Digital Control Board
Product Overview

Motorola MVME172-263 is a digital control board based on the VMEbus architecture, with model 01-W3183F-10A indicating its specific hardware version and revision number. This module is used in embedded control systems to implement digital input/output (DI/DO) control and is widely used in industrial automation, testing and measurement, machine tool control, and communication systems. MVME172-263 can work in conjunction with MVME172 series CPU modules and other I/O boards, providing reliable digital control interfaces and signal management capabilities.

Technical Specifications

Bus interface: VMEbus standard, supports 16/32-bit data transmission

Digital quantity interface:

Multi channel digital input (DI)

Multi channel digital output (DO)

Output can drive relays or switch loads

Control logic:

Support pulse, timing control, and status feedback

Configurable trigger conditions and interrupt response

Compatibility: Compatible with MVME172 series CPU modules and other VMEbus boards

Reliability design: Industrial grade design with anti-interference and short-circuit protection functions

Work environment: Suitable for industrial temperature range, long-term continuous operation
