Motorola MVME204-2 Communication Module

Product manual:

Motorola MVME204-2 Communication Module
Product Overview

Motorola MVME204-2 is a communication module based on the VMEbus architecture, belonging to the MVME200 series. This module is used to provide high-speed and reliable data communication interfaces in embedded control systems, and can work in conjunction with MVME series CPU modules to support data exchange in industrial automation, testing systems, power dispatching, and communication network systems. MVME204-2 has a modular design that can be flexibly integrated into the VME bus system to achieve multi-channel communication and bus resource management.

Technical Specifications

Bus interface: VMEbus standard, supports 16/32-bit data transmission

Communication interface:

Serial interface (RS-232/RS-422/RS-485 optional)

Parallel interface (for high-speed data transmission)

Can be configured for multi-channel data communication

Data rate: Supports 9600 bps -1 Mbps (serial) depending on the interface type

Control function:

Data buffering and interrupt management

Support DMA transfer

Can communicate synchronously with CPU module

Compatibility: Compatible with MVME200 series CPU modules and other VME expansion boards

Work environment: Industrial grade design, supporting long-term stable operation, strong anti-interference ability

Application scenarios

Industrial Automation

Realize real-time data exchange between PLC, DCS systems and peripheral devices.

Laboratory testing and measurement

Provide multi-channel data acquisition and transmission capabilities.

Power and Energy Systems

Used for signal and data transmission in power grid dispatching and substation automation systems.

Communication network equipment

Used for data communication in embedded switches, routers, or control nodes.

DCS

Multi board collaborative control achieves data synchronization and task distribution within the bus.

Motorola MVME204-2  Product details picture:
