Motorola MVME5110-2261 Single Board Computer

Product manual:

Product Overview

Motorola MVME5110-2261 is a specific model of MVME5100 series single board computer (SBC), based on PowerPC architecture processor and supporting VMEbus system. It is widely used in high reliability scenarios such as industry, national defense, and telecommunications, and can serve as the central processing and control core of the system. This model balances performance in terms of computing performance, I/O expansion, and system reliability, making it suitable for long-term stable operation of embedded applications.

Technical parameters (refer to MVME5110 series)

Processor: Motorola PowerPC 750 (MPC750), with a clock speed of approximately 366MHz (this model number "2261" usually corresponds to a 366MHz configuration).

Cache:

Level 1 cache: 32KB instructions+32KB data

Second level cache: 1MB external L2 cache

Memory:

SDRAM main memory: 64MB~512MB (expandable)

Flash/EPROM: Used for firmware and boot loading

Bus interface:

VME64 standard interface (compatible with A24/A32 addresses and D32/D64 data transmission)

PCI Local Bus supports expansion modules

I/O interface:

10/100Mbps Ethernet port

Multiple serial ports (RS-232/RS-422 optional)

SCSI controller interface (for external storage)

Parallel port and universal I/O

Operating system support: VxWorks, Lynx OS, pSOS, Linux and other embedded/real-time operating systems

Power supply method: Powered by VME backplane (+5V/± 12V)

Application scenarios

Industrial automation: as the main control core of production equipment, robots, and process control systems.

Telecommunications and Networks: Used for switches, communication base stations, and data transmission nodes.

Defense and aerospace: deployed on command and control, radar processing, and mission computing platforms.

Transportation: Embedded core in railway, subway, and aviation ground control systems.

Testing and Measurement: Integrated into VME instrument equipment to achieve high-speed data acquisition and analysis.

Motorola MVME5110-2261 Product details picture:

MVME5110-2261
