Motorola MVME7100-0173 Communication Module

Product manual:

Product Overview

Motorola MVME7100-0173 is a communication expansion module for MVME7100 series single board computers (SBC), used in VME bus systems to achieve high-speed data transmission and external device interface management. This module, when used in conjunction with the MVME7100 series motherboard, can provide reliable communication capabilities for industrial, defense, and communication systems.

Technical parameters (refer to the characteristics of communication modules in the same series)

Bus interface: VME64 bus, compatible with A24/A32 address mode and D32/D64 data width

Processing capability: dependent on the main CPU module, the module itself is mainly responsible for I/O management

Communication interface type:

Serial interface (RS-232/RS-422/RS-485 multi-channel, can run simultaneously)

Ethernet interface (10/100Mbps, optional)

Can support dedicated buses or industrial protocol interfaces

Buffer and Interrupt: Integrated FIFO buffer, supports interrupt triggering, reduces motherboard CPU load

Power supply: Powered by VME backplane (+5V/± 12V)

Work environment: Industrial grade design, supporting continuous operation and wide temperature range

Product application scenarios

Industrial automation: data communication and control between PLC, sensors, and actuators

Telecommunications system: data interface management of switches, base stations, and signal nodes

Military and Aviation: Data Transmission and Reception Module of Embedded Command and Control System

Traffic Control: Data Communication Interface for Railway and Subway Signal Systems

Testing and Measurement: Cooperate with the main control board of the instrument equipment to achieve high-speed data acquisition and communication

Product Features

Multi channel communication: supports multiple serial interfaces, facilitating parallel data transmission within the system

High reliability: Industrial grade design, suitable for continuous 7 × 24-hour operation

Reduce main CPU load: onboard FIFO buffer and interrupt mechanism for efficient data processing

Good compatibility: seamlessly integrated with MVME7100 series CPU modules and VME bus systems

Flexible application: Supports multiple industrial communication standards such as RS-232, RS-422, RS-485, etc

Motorola MVME7100-0173 Product details picture:
