Motorola MVME712-101 Expansion Module

Brand:Motorola
Model:MVME712-101
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Motorola MVME712-101 Expansion Module

Product manual:

Motorola MVME712-101 Expansion Module
Product Overview

Motorola MVME712-101 is an extension module based on the VMEbus architecture, used for MVME712 series single board computer systems. This module aims to expand the I/O, storage, or communication capabilities of the CPU module, provide additional interfaces and functional support, and enable the system to meet more complex embedded control, industrial automation, and real-time data processing requirements. MVME712-101 can work together with MVME712 series CPU modules and other VME expansion boards to achieve modular expansion of system functions.

Technical Specifications

Bus interface: VMEbus standard, supports 16/32-bit data transmission

Extended functions:

Scalable I/O channels (digital/analog interfaces)

Support additional storage or cache expansion (depending on configuration)

Communication interface expansion (serial/parallel ports, optional)

Control function:

Synchronize communication with CPU module

Interrupt handling and status monitoring

Support DMA data transfer

Compatibility: Compatible with MVME712 series CPU modules and other VME expansion modules

Work environment: Industrial grade design, strong anti-interference ability, suitable for long-term continuous operation
