Motorola MVME714M multiplexer module

Product manual:

Motorola MVME714M multiplexer module
Product Overview

The Motorola MVME714M is a multiplexer (MUX) module based on the VMEbus architecture, used for the MVME714 series of single board computer systems. This module is used for centralized management and switching of multiple digital or analog signal channels, selectively transmitting different input signals to CPU modules or other processing units, achieving efficient signal scheduling and data management. MVME714M can work in conjunction with MVME714 series CPU modules and other VME expansion modules, and is an important component of industrial automation, testing and measurement, and embedded real-time control systems.

Technical Specifications

Bus interface: VMEbus standard, supports 16/32-bit data transmission

Reuse function:

Selection of multi-channel digital or analog signal channels

Programmable switching logic

Support synchronous or asynchronous signal reuse

Control function:

Signal selection under CPU control

Support interrupts and status feedback

Compatible with data exchange and bus control with other modules

Compatibility: Compatible with MVME714 series CPU modules and VME expansion modules

Work environment: Industrial grade design, strong anti-interference ability, suitable for long-term continuous operation

Application scenarios

industrial automation control

Centralized management of multi-sensor data to achieve efficient scheduling of digital/analog signals.

Machine Tool and Motion Control System

Manage multiple sensor or actuator channels to achieve multi axis control and status monitoring.

Laboratory Testing and Measurement System

Multi channel signal acquisition, testing data switching, and experimental equipment interface management.

Communication and Embedded Systems

Multiplexing of multiple signal data to achieve data scheduling for embedded communication nodes.

Energy and Power Systems

Centralize the selection and transmission of signals from multiple monitoring points or sensors to achieve automated control and monitoring.

Motorola MVME714M  Product details picture:
