Motorola VME162PA-242LE Embedded Controller

Product manual:

Motorola VME162PA-242LE Embedded Controller
Product Overview

Motorola VME162PA-242LE is an embedded controller module based on the VMEbus architecture, belonging to the MVME162 series. This controller integrates CPU, memory, bus interface, and I/O control functions, and is used for industrial automation, machine tool control, testing and measurement, and embedded real-time systems. It can serve as the core computing unit of the system, working in conjunction with the VME bus and other expansion modules to achieve high-speed data processing and reliable control.

Technical Specifications

Processor: Motorola MC68EC030/MC68030 series CPU

Memory:

RAM: 2 MB -8 MB expandable

ROM/Flash: Used for firmware and boot programs

NVRAM: with real-time clock function

Bus interface: VMEbus standard, supports 16/32-bit data transmission

I/O interface:

Multi channel serial interface (RS-232/RS-422)

Parallel Interface

Timer and watchdog function

Control function:

Bus arbitration and DMA data transfer

interrupt management

Support self inspection and status monitoring

System compatibility: Supports embedded real-time operating systems such as VxWorks and pSOS

Work environment: Industrial grade design, suitable for wide and long-term continuous operation

Application scenarios

Industrial Automation and Process Control

Manage data collection and execution control for production lines, PLC systems, and industrial equipment.

Machine Tool and Motion Control System

Support multi axis synchronous control, pulse output, and servo drive management.

Testing and Measurement System

Data collection, experimental equipment control, and signal processing platform.

Communication and Embedded Systems

Embedded network nodes and protocol processing.

Energy and Power Systems

Real time monitoring and control of power generation, transformation, and distribution systems.

Motorola VME162PA-242LE Product details picture:

VME162PA-242LE

Motorola VME162PA-242LE product video
