MTL MTL5544 Safety Barrier

Product manual:

1、 Basic Information
Product model: MTL5544

Manufacturer: MTL Instruments (now Eaton MTL brand)

Product type: Safety Barrier/Intrinsic Safety Barrier

Application field: Used for electrical signal isolation and intrinsic safety protection in explosion-proof areas, ensuring the safety of equipment and personnel

2、 Function Description
Main functions:

Convert high-energy signals into Intrinsic Safety (IS) signals

Limit the current and voltage passing through the circuit to prevent ignition of flammable gases or dust in hazardous environments

Implement secure isolation to protect on-site instruments and control systems

Protection method:

Current limitation and energy limitation

Overvoltage and short circuit protection

Fault safety design, automatically disconnecting or limiting energy output in case of malfunction

3、 Technical parameters
Number of channels: Single channel safety barrier

Input voltage: usually supports 0~30 V DC input

Maximum current limit: approximately 100 mA (specific value depends on product specifications)

Working temperature range: -40 ° C to+70 ° C

Certification standards:

Compliant with international explosion-proof certification standards such as ATEX and IECEx

Suitable for hazardous areas 0, 1, and 2 environments

Isolation voltage: High voltage isolation ensures safe isolation between the control system and the hazardous area

Response time: Fast response, ensuring real-time security protection

Product details picture:
