MTL MTL5546 Isolation Driver

Brand:MTL
Model:MTL5546
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

MTL MTL5546 Isolation Driver

Product manual:

1、 Basic Information
Product model: MTL5546

Manufacturer: MTL Instruments (now Eaton MTL)

Product type: Isolating Driver/Isolator Amplifier

Application scope: In industrial process control systems, provide signal isolation and drive functions, protect control systems and field equipment

2、 Function Description
Signal isolation: achieving electrical isolation between input and output, eliminating ground loop interference, and improving system anti-interference capability

Signal driven: Enhance signal driven capability to ensure stability of long-distance signal transmission

Compatible with multiple signal types: compatible with standard analog signal inputs (such as 4-20mA, 0-10V, etc.)

Linear amplification: provides precise linear signal transmission, maintaining signal accuracy and integrity

High reliability design: suitable for harsh industrial environments, stable operation

3、 Technical parameters
Input signal range: typically supports 4-20mA current signals and other standard analog signals

Output signal range: 4-20mA or 0-10V analog signal output

Isolation voltage: ≥ 1500Vrms, ensuring complete isolation of input and output

Power supply method: usually 24V DC power supply

Response time: Fast response, meeting real-time control requirements

Working temperature range: -40 ° C to+70 ° C

Installation method: DIN rail installation, convenient for industrial site use

4、 Application Fields
Chemical, petroleum, and natural gas process control systems
