Novellus Systems 02-052474-00 DC terminal block

Brand:Novellus Systems
Model: 02-052474-00
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Novellus Systems 02-052474-00 DC terminal block

Product manual:

Novellus Systems 02-052474-00 DC Wiring Board is a module used for power distribution or signal wiring functions within Novellus semiconductor manufacturing equipment. It is mainly used in the system for the organization, distribution, and interface connection of DC power supply lines, and is one of the indispensable basic components in equipment electrical systems.

1、 Basic Information
Product Name: DC Wiring Board

Model: 02-052474-00

Manufacturer: Novellus Systems Inc. (merged into Lam Research)

Application areas: Power distribution, signal wiring, and bridging of semiconductor devices

Module Type: Backboard/Terminal Block

2、 Function Description
Functional category description
DC power distribution provides multiple power output ports, distributing the main power supply (such as 24V, 48V, etc.) to various sub modules of the equipment (such as sensors, actuators, solenoid valves, control boards, etc.)
Signal sorting distributes low-voltage signals from the main control or control module to each executing component through a unified wiring method
Grounding/shielding management provides a good grounding or shielding wire connection channel to reduce electromagnetic interference
Some versions of safety isolation may integrate basic protection measures such as overcurrent protection and fuse holders

3、 Typical application locations
This wiring board may be installed in the following devices or areas:

Inside the power distribution cabinet of the Concept series PECVD/SACVD/HDCPVD systems

Rear wiring area of electrical control box or equipment

Concentrated point of I/O wiring near the process chamber

Used in conjunction with DC power supply or relay/fuse modules
