Novellus Systems 03-283968-00 Vector Board

Brand:Novellus Systems
Model: 03-283968-00
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Novellus Systems 03-283968-00 Vector Board

Product manual:

The Novellus Systems 03-283968-00 Vector Board is a specialized signal distribution and integration interface board used in Novellus semiconductor manufacturing equipment.
As a high-density signal bridging platform, this module undertakes complex signal integration, relay, distribution, and isolation conversion tasks between multiple subsystems,
Widely used in process control systems for CVD, ALD, PVD and other equipment.

1、 Basic Information
Project Content
Product Name: Vector Interface Board
Model 03-283968-00
Manufacturer Novellus Systems Inc. (now Lam Research)
Component type control/I/O signal centralized board, high channel interface module
Application signal summary, relay transmission, module interconnection and allocation

2、 Core functions
Functional category description
Signal relay and centralized management of signals from multiple controllers/actuators/sensors
Channel distribution distributes the main control signal to target modules (such as heaters, vacuum valves, MFCs, etc.) according to their functions
Interface conversion TTL ↔ CMOS、RS-232/485 ↔ Serial/parallel interface protocol conversion
Electrical isolation protection board for onboard optocouplers, surge protection, TVS suppressors, anti misconnection circuits, etc
Multi channel parallel processing supports simultaneous operation of tens to hundreds of channels, adapting to the control requirements of complex process systems
