Novellus Systems 22-8875-004 Dual DC Motor Board

Brand:Novellus Systems
Model:22-8875-004
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Novellus Systems 22-8875-004 Dual DC Motor Board

Product manual:

Novellus Systems 22-8875-004 Dual DC Motor Board
It is a driver module designed specifically for Novellus semiconductor equipment, mainly used to control the operation of two DC motors.
This board provides precise speed regulation, steering control, and protection functions for DC motors,
Widely used in motion platforms, valve drives, or positioning systems in equipment to ensure stable and efficient operation of mechanical components.

1、 Basic Product Information
Product model: 22-8875-004

Product Name: Dual DC Motor Board

Manufacturer: Novellus Systems (now a subsidiary of Lam Research)

Functional positioning: Dual channel DC motor drive and control module

2、 Core functions
Function Point Description
Dual motor drive supports driving two DC motors simultaneously, independently controlling speed and steering.
Speed regulation achieves precise speed control through analog or digital signals, adapting to different operating conditions.
Overload protection is equipped with overcurrent, overvoltage, and overheating protection mechanisms to ensure the safety of the motor and drive board.
The feedback interface supports encoder or Hall sensor signal input to achieve closed-loop control.
State monitoring provides an interface for monitoring the operation status of motors, facilitating system diagnosis and maintenance.

3、 Typical application areas
Sports platform driver
Control the precise movement of the crystal cone or detection platform to ensure positioning accuracy and stability.

valve actuator
Drive the DC motor valve in the vacuum system to achieve fast response and precise switching.

Mechanical arm or automated handling system
Control the DC motor to complete mechanical actions and cooperate with the system to complete automation processes.

Other equipment components that require dual DC motor control
