Novellus Systems 76-380346-01 Brake Circuit Board

Brand:Novellus Systems
Model: 76-380346-01
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Novellus Systems 76-380346-01 Brake Circuit Board

Product manual:

Novellus Systems 76-380346-01 Brake Circuit Board
It is a key electronic module designed specifically for Novellus semiconductor manufacturing equipment,
Mainly used for controlling and managing the braking function of motors in mechanical systems,

1、 Basic Product Information
Product model: 76-380346-01

Product Name: Brake Circuit Board

Manufacturer: Novellus Systems (now a brand under Lam Research)

Main purpose: Motor braking control and protection

2、 Core functions
Function point description
Motor braking control realizes the braking function of DC or AC motors, including dynamic braking and mechanical braking control.
Braking status monitoring provides feedback on the execution status of braking, ensuring that the braking action is completed as expected.
Protection functions include overcurrent protection, short circuit protection, etc., to prevent damage to the braking circuit and motor.
Interface compatibility is closely coordinated with the main control system and motor drive module to achieve linkage control.

3、 Typical application areas
Sports platform and carrier control
Ensure that the motion platform stops accurately during wafer processing or inspection to prevent impact damage.

Mechanical arm brake
Realize precise stopping of the robotic arm during automated handling or positioning processes.

Valve or driving device safety brake
Prevent accidental valve operation during power outages or emergency situations.

emergency shutdown system
As part of the device security system, respond quickly to emergency shutdown commands.
