PCS124PS-200 power module

Model:PCS124PS-200
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

PCS124PS-200 power module

Product manual:

PCS124PS-200 power module product features
PCS124PS-200 is a specialized 200W industrial grade DC-DC power module for ABB Bailey PCS series, designed to provide stable, isolated, and low ripple 24V DC power supply for industrial control systems, suitable for harsh industrial environments.
Rated power of 200W, supporting 115% peak overload (230W) for 60 seconds, suitable for short-term high load conditions.
Standard 24V DC output, voltage accuracy ± 0.8%, ripple noise ≤ 50mV, meeting the power supply requirements of precision equipment.
Isolated topology, input and output isolation voltage 2250VDC, insulation resistance ≥ 200M Ω, safe and reliable electrical use.
Wide DC input 18-36VDC (4:1 aspect ratio), compatible with 24V battery packs and industrial standard power supply circuits.
Intelligent temperature control heat dissipation (natural convection+auxiliary heat dissipation), noise ≤ 30dB, no fan wear hazard.
Wide temperature operation -40 ℃~70 ℃, stable operation within an altitude of 5000m (moderate derating above 3000m).
Multiple protection: reverse connection, ± 2kV surge, over temperature, over current, short circuit self recovery, comprehensive protection system.
Support remote on/off control, response delay ≤ 400 μ s, convenient for centralized operation and maintenance.
Sealed metal casing, IP21 protection, impact and vibration resistance, in compliance with industrial grade standards.
Compatible with TS-35 standard DIN rail, with a width of only 40mm, it can be densely deployed and save cabinet space.
Built in secondary EMI filter, compliant with EN 55022 standard, no electromagnetic interference from peripheral devices.
MTBF exceeds 500000 hours, 100% full load aging test, with a service life of over 8 years.
Cage type terminal block, firmly connected to prevent detachment, multi-color identification, easy and efficient installation and maintenance.
The PCS124PS-200 power module, with high isolation, low ripple, wide temperature durability, and full protection as its core, is a key component for stable power supply in ABB PCS control systems.
