PFSA140 3BSE006503R1 Supply Unit Module

Brand:ABB
Model:PFSA140 3BSE006503R1
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

PFSA140 3BSE006503R1 Supply Unit Module

Product manual:

Brief introduction
ABB PFSA140 3BSE006503R1 is a DC power module designed by ABB for its Freelance DCS (AC 800F system),
Used to provide stable power support for controllers, communication modules, I/O modules, etc.
It is an indispensable basic power supply unit in the system.

2、 Main technical parameters
Project parameter description
Product model PFSA140
Order number 3BSE006503R1
Input voltage range 18~32 VDC (typical 24 VDC)
Stable output voltage of 24 VDC for internal module use
Output power is approximately 30 W (depending on system load)
Working temperature -20 ° C to+60 ° C
Installation method: DIN rail installation or modular insertion system backplane
Status display LED status indicator light (power supply status, fault, etc.)
Electrical protection has overvoltage, overcurrent, and short-circuit protection
Redundancy support supports dual module redundant heat backup operation mode
Industrial grade design with a service life that meets long-term stable operation requirements

3、 Function and Features
High reliability power supply: ensuring the continuous operation of DCS control system and preventing system abnormalities caused by voltage fluctuations.

Comprehensive protection mechanism: equipped with overload, overvoltage, and short-circuit protection to improve system safety.

Modular structure: easy to integrate into ABB Freelance control systems for quick installation and replacement.

Clear status monitoring: LED indicator lights reflect the real-time operation status of the module, facilitating on-site diagnosis.

Support redundant power mode: can be seamlessly backed up with a second PFSA140 to improve system reliability.
