PHOENIX CONTACT QUINT-DIODE/40 2938963 Redundant Module

Brand:PHOENIX CONTACT
Model:QUINT-DIODE/40 2938963
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

PHOENIX CONTACT QUINT-DIODE/40 2938963 Redundant Module

Product manual:

PHOENIX CONTACT QUINT-DIODE-40 (model 2938963) is an industrial power redundancy module,
Mainly used to achieve redundant protection of power input, ensuring that the system can automatically switch from the backup power supply in case of a main power failure, and ensuring stable power supply.

Main parameters:

Input voltage range: 0 V DC to 30 V DC

Rated input current: Single circuit 40 A, dual circuit 20 A each

Output voltage: 24 V DC

Output current: maximum 40 A

Maximum power consumption: approximately 20 W (under rated load)

Efficiency: greater than 97%

Electrical isolation: 1 kV between input/output and ground

Working temperature: -25 ° C to+70 ° C (derating is required for use above 60 ° C)

Protection level: IP20, suitable for installation in enclosed control cabinets

Installation method: DIN rail installation

Connection method: Screw terminal, supporting wires ranging from 0.5 to 16 mm ²

The application scope includes automation control systems, process control, power monitoring
Scenarios that require high reliability power supply, such as communication equipment power supply and traffic control systems.

Product details picture:

QUINT-DIODE/40 2938963
