PHOENIX CONTACT QUINT-PS-100-240AC/24DC/140 Power Supply Module

Brand:PHOENIX CONTACT
Model:QUINT-PS-100-240AC/24DC/140
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

PHOENIX CONTACT QUINT-PS-100-240AC/24DC/140 Power Supply Module

Product manual:

PHOENIX CONTACT QUINT-PS-100-240AC/24DC/40 is a highly reliable, industrial grade power supply module,
Belonging to the QUINT POWER series, designed specifically for harsh industrial applications,
It has high power density, redundant power supply capability, and multiple protection mechanisms.

Basic information
Product model: QUINT-PS-100-240AC/24DC/40

Order number: 2938879

Manufacturer: PHOENIX CONTACT

Product type: Switching power supply, DIN rail installation

Main technical parameters
input parameter

Input voltage range: 100-240 V AC (acceptable 85-264 V AC)

Simultaneously supporting 90-350 V DC input

Power efficiency: up to 94%

Start surge current:<15 A

Output parameters

Output voltage: 24 V DC (adjustable range: 18-29.5 V)

Power: 960 W

Support Power Boost mode: Sustainable output of 45 A current

Ripple voltage:<30 mVpp

Fast dynamic response, suitable for starting heavy load devices

Protection function

Short circuit protection (electronic automatic recovery)

Output overvoltage protection (maximum<35 V)

Undervoltage monitoring and alarm function

Thermal protection (automatic derating or shutdown when temperature rise is too high)

Environmental and structural parameters

Working temperature: -25 ° C to+70 ° C (derating required for temperatures>60 ° C)

Cooling method: natural convection

Protection level: IP20 (applicable to the interior of control cabinets)

Installation method: DIN rail installation

Size: 240 × 130 × 125 mm

Weight: Approximately 3.8 kg

Product details picture:

QUINT-PS-100-240AC/24DC/140
