Rexroth PPC-R22.1N-T-Q2-G2-NN-FW servo controller
Brand:Rexroth
Model:PPC-R22.1N-T-Q2-G2-NN-FW
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
Rexroth PPC-R22.1N-T-Q2-G2-NN-FW servo controller
Product manual:
1、 Product Overview
Brand: Bosch Rexroth
Model: PPC-R22.1N-T-Q2-G2-NN-FW
Product type: Industrial multi axis motion controller
Series: PPC-R Series
Typical applications: Multi axis servo system control, CNC system, robot automation, packaging machinery, etc
2、 Structure and Module Configuration Description
The segmented meanings of the controller model are as follows:
PPC-R22.1N: Main controller module, installed in RMB02.2 rack
T: Equipped with Ethernet communication interface
Q2: Pre installed DAQ03 module (dual axis control or high-speed input)
G2: Pre installed LAG module (main encoder interface module)
NN: No additional modules installed (U3, U4 empty spaces)
FW: Firmware needs to be ordered separately or loaded through a storage card
3、 Technical parameters
Power supply voltage: 24V DC
Current consumption: maximum approximately 1.2A
Installation method: Vertical plug-in installation on Rexroth RMB02.2 rack
Cooling method: natural air cooling (combined with cabinet ventilation)
Dimensions: Approximately 83mm in width, 182mm in height, and 150mm in depth
Protection level: IP20 (installed in the control cabinet)
Expansion slots: 3 in total (U2, U3, U4)
4、 Main functions
Support multi axis synchronous control
Compatible with Rexroth IndraDrive and EcoDrive servo drives
Support GPP10/GPP11 firmware programs
Support high-speed input, encoder feedback, and logic control
Provide real-time motion control (including interpolation, speed control, position control)
Support Profibus, SERCOS, DeviceNet (through corresponding modules)
Provide diagnostic LED display for easy fault identification
5、 Application Fields
Numerical Control System (CNC)
Automated assembly line
Multi axis servo drive system
Packaging, printing, and textile machinery
Industrial Robot Control System
Woodworking and metalworking equipment
Product details picture:
