SANYO DENKI MC1K-U100V servo drive

Product manual:

1、 Product Overview

MC1K-U100V belongs to the SANYO DENKI MC1K series single axis motion control module, which integrates servo drive function,
Can directly drive servo motors and perform motion control tasks.
It supports position, speed, and trajectory control, suitable for medium to high power industrial automation systems.

2、 Main technical parameters (typical values)

Number of control axes: single axis

Output current level: approximately 100A

Input power supply: AC 200-230 V three-phase

Control interface: supports digital pulse commands and analog input

Feedback device: supports absolute or incremental encoders

Motion control ability: point-to-point positioning, speed control, trajectory control

Regeneration/braking function: Built in braking resistor, capable of recovering regenerative energy

Cooling method: natural air cooling or forced air cooling

Working environment: normal temperature, humidity not exceeding 90%, no condensation

3、 Product Features

integrated design
Controller and driver integration reduces system wiring and volume.

Medium to high power output
Can drive servo motors with high rated current to meet high load requirements.

Advanced motion control
Supports trajectory control and multitasking control, suitable for complex motion requirements.

High compatibility
High compatibility with SANYO DENKI servo motors, easy maintenance and replacement.

Protection and perfection
Equipped with overcurrent, overvoltage, undervoltage, overheating, encoder abnormality protection, etc.

4、 Application scenarios

Single axis precision positioning equipment

Numerical Control Machine Tools and Industrial Automation Systems

Equipment requiring compact control modules

System upgrade and replacement, simplifying control and wiring

SANYO DENKI MC1K-U100V  Product details picture:

MC1K-U100V

SANYO DENKI MC1K-U100V product video
