SANYO DENKI PY2A030A3-AL servo drive

Product manual:

1、 Main specifications

Input power supply: single-phase AC 200-230 V, 50/60 Hz

Input current: approximately 10 A

Output (drive motor end): three-phase, output current of about 5.2 A, output voltage of 0-326 V, PWM frequency of about 8 kHz

Suitable motor power: approximately 1.5 kW

Maximum applicable motor speed: approximately 4500 rpm

Electrical/mechanical time constant: approximately 13 ms for electrical and 0.59 ms for mechanical

2、 Product Features

compact design
Belonging to the PY2 series, the volume is smaller than traditional models, saving installation space.

Multi mode control
Supports position, speed, and torque control modes, suitable for medium power servo systems.

Tuning function
Including offline/online automatic tuning and filtering tuning, it can optimize motor performance.

Reliable heat dissipation
It is recommended to install vertically and maintain a ventilated space to control temperature rise.

3、 Usage suggestions and precautions

The driver needs to match the rated power and current of the motor to avoid overload.

Ensure stable input power supply and good grounding during installation to prevent electrical interference.

You need to provide or confirm the circuit fuse yourself to prevent overload.

Wiring should minimize high-frequency PWM interference and comply with electromagnetic compatibility requirements.

SANYO DENKI PY2A030A3-AL  Product details picture:

PY2A030A3-AL
