SANYO DENKI Q3AA13150HBZTA servo motor

Product manual:

SANYO DENKI Q3AA13150HBZTA servo motor

Basic Parameters:

Brand: SANYO DENKI (Sanyo Electric)

Model: Q3AA13150HBZTA

Series: SANMOTION Q Series

Type: Three phase AC servo motor

Rated power: approximately 1.5 kW

Rated current: approximately 7.8A (peak 8.9A)

Weight: Approximately 12.3 kg

Shaft diameter: approximately 22 mm

Product Features:

High precision positioning control, fast response speed, suitable for mid to high end automation equipment.

Stable torque output and strong overload capacity.

Built in high-resolution encoder ensures smoothness and accuracy of motion control.

Low vibration, low noise design, smooth operation.

Compact structure, suitable for installation environments with limited space.

Has good heat dissipation performance and can operate continuously and efficiently.

Precautions for use:

The rated voltage of the motor must match the output voltage of the driver.

The optional servo drive should be able to provide sufficient peak current.

During installation, ensure good concentricity of the coupling to avoid excessive axial or radial stress.

Maintain good ventilation and avoid prolonged overload operation.

Check if the signal type of the motor encoder is compatible with the control system.

Regularly clean the motor casing to prevent dust accumulation from affecting heat dissipation.

SANYO DENKI Q3AA13150HBZTA Product details picture:

Q3AA13150HBZTA

SANYO DENKI Q3AA13150HBZTA product video
