SANYO DENKI Q3AA18200BBZTA AC servo motor

Brand:SANYO DENKI
Model:Q3AA18200BBZTA
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

SANYO DENKI Q3AA18200BBZTA AC servo motor

Product manual:

SANYO DENKI Q3AA18200BBZTA AC servo motor
Product Introduction

SANYO DENKI Q3AA18200BBZTA is a high-performance AC Servo Motor from SANYO DENKI
A model in the (AC servo motor) series, belonging to the SANMOTION Q series.
This series is known for its high response, high precision, and compact design, developed specifically for automation equipment and precision control systems.

Main performance characteristics

High response and high control accuracy
Adopting a low moment of inertia and high magnetic flux density design to achieve excellent acceleration and deceleration performance and dynamic response capability.
When used in conjunction with Shanyang servo drives, precise position control at the micrometer level can be achieved.

Strong output and energy-saving design
High electromagnetic efficiency, low temperature rise, able to output large torque in a small volume, meeting high load conditions.
Optimized winding technology is adopted in the design to effectively reduce energy consumption.

Built in high-resolution encoder
Built in high-precision absolute value encoder (usually with a resolution of 20 bit or higher), achieving precise position feedback and smooth operation.

Compact and lightweight structure
The motor adopts high-strength aluminum alloy shell and optimized heat dissipation structure, with small volume and light weight, making it easy to install in equipment with limited space.

Low noise, low vibration
Special rotor balance and bearing arrangement significantly reduce operating noise and mechanical vibration.

Multiple protection design
It has multiple protection functions such as overheating, overcurrent, overload, etc., suitable for long-term stable operation.

Typical technical parameters (reference)

Rated power: approximately 2.0 kW

Rated torque: approximately 9.5 N · m

Maximum speed: 5000 rpm

Encoder type: Absolute/Incremental (optional)

Cooling method: natural air cooling

Protection level: IP65 (excluding shaft extension)

Installation method: flange installation
