SCXI-1000 slot chassis

Product manual:

Overview of SCXI-1000 Slot Chassis

Type: Modular Slot Chassis/Rack

Core function: Provide unified power supply, backplane connection, and slot management for SCXI series modules (such as signal conditioning modules, sensor interface modules, control modules, etc.)

Typical installation method: laboratory desktop or industrial cabinet

Application positioning: Hardware carrier for data acquisition systems, experimental measurement and control systems, or industrial automation measurement and control platforms

Main functions

Module power supply

Provide stable power supply for the inserted SCXI module

Support multiple modules working simultaneously to ensure overall system stability

Signal backplane connection

Provide standardized backplane bus

Each module is interconnected through a backplane to achieve the transmission of data and control signals

System Expansion

Support the combination of multiple SCXI modules

Modules can be added or replaced as needed to achieve flexible system upgrades

status indicator

Indicate the power status of the chassis and the working status of the modules

Improve maintenance efficiency and system observability

Technical Features

Modular design: Different numbers of modules and slots can be selected according to requirements

Industrial grade reliability: durable, stable, suitable for long-term operation

Good compatibility: compatible with all modules in the SCXI series

Easy maintenance: easy to plug and unplug modules, supports hot swapping (depending on module specifications)

High signal integrity: Backplane design ensures stable transmission of data and control signals
