Siemens 6EP1437-3BA00 power module

Brand:Siemens
Model:6EP1437-3BA00
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Siemens 6EP1437-3BA00 power module

Product manual:

Siemens 6EP1437-3BA00 is a high-performance power module in the Siemens SITOP series, belonging to the SITOP PSU8600 intelligent power system. This power supply is designed specifically for industrial automation systems, with extremely high reliability and communication capabilities. It supports integration with upper control systems through PROFINET and is suitable for industrial applications that require high levels of power intelligence, diagnosability, and redundancy.

1、 Basic Information
Project Content
Brand Siemens Siemens
Series SITOP PSU8600
Product model 6EP1437-3BA00
Product Name: Power Supply Unit
Output type: Programmable DC power output
Installation method: DIN rail installation
Communication interfaces PROFINET, USB, OPC UA (via extension)

2、 Technical specifications and parameters
Parameter values
Input voltage AC 400-500 V (three-phase)
Input frequency 50/60 Hz
Output voltage 24 V DC (adjustable range: 22-28 V)
Maximum output current of 40 A
Rated output power 960 W (24 V × 40 A)
Efficiency ≥ 94%
Insulation protection level Class I (grounding protection)
Communication interface PROFINET (supporting S7 and TIA Portal integration)
Working temperature -25 ° C~+70 ° C
Cooling method: natural ventilation
Size 145 × 125 × 150 mm (height × width × depth)
Certification standards such as CE, UL, CSA, EN 61010, etc
