Siemens 6ES7135-6HD00-0BA1 Analog Output Module

Brand:Siemens
Model: 6ES7135-6HD00-0BA1
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Siemens 6ES7135-6HD00-0BA1 Analog Output Module

Product manual:

Siemens 6ES7135-6HD00-0BA1 is an analog output module in the Siemens SIMATIC ET 200SP series, used to convert digital signals in PLC systems into analog signal outputs to control analog devices on site, such as frequency converters, valves, regulators, etc.

1、 Basic Product Information
Project Content
Product model 6ES7135-6HD00-0BA1
Product Name SIMATIC ET 200SP AO 4xU/I ST Analog Output Module
SIMATIC ET 200SP series
Module Type Analog Output Module AO
Signal type Voltage/Current (U/I)

2、 Main technical parameters
Parameter Description
Number of channels: 4 analog output channels
The output type can be configured as voltage output (0-10 V) or current output (0/4-20 mA)
Resolution 16 bits
The accuracy is usually ± 0.5% (depending on the mode and load)
Electrical isolation between isolation channel and backplane bus
Load capacity voltage output ≥ 1 k Ω, current output ≤ 600 Ω
Power supply voltage 24 V DC
Module width 15 mm (based on ET 200SP compact structure)
Installation method: rail installation (to be used together with BaseUnit)
The product version (BA) is BA01

3、 Function and Features
Supports 4 independent configurable outputs (voltage/current mode);

✅ High resolution output, suitable for precision analog control;

✅ Channel isolation ensures stable operation of the system;

Seamless integration with ET 200SP distributed I/O system;

✅ The module status can be indicated by LED, which facilitates fault diagnosis;

✅ Compact design, saves installation space, and is easy to expand.
