Siemens 6ES7317-2FK14-0AB0 Central Processing Unit

Brand:Siemens
Model:6ES7317-2FK14-0AB0
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Siemens 6ES7317-2FK14-0AB0 Central Processing Unit

Product manual:

Siemens 6ES7317-2FK14-0AB0 is a high-performance central processing unit (CPU) in the Siemens S7-300 series, with the model number CPU 317-2 PN/DP. It has good processing capabilities, integrated Ethernet (PROFINET) and PROFIBUS interfaces, and is suitable for medium to large automation control systems.

1、 Product Overview
Project Description
Product model 6ES7317-2FK14-0AB0
Product Name SIMATIC S7-300 CPU 317-2 PN/DP Central Processing Unit
Series SIMATIC S7-300
Manufacturer Siemens
CPU type: CPU 317-2 PN/DP
Large scale PLC control systems in application fields such as factory automation, process control, power, transportation, etc

2、 Main technical parameters
Parameter Data Description
The processor performance is above average and suitable for complex control tasks
Work memory 1 MB (load memory)/256 KB (work memory)
Instruction execution time bit operation is about 0.06 μ s, word operation is about 0.1 μ s
Digital I/O point support can be expanded through modules, supporting a large number of digital inputs/outputs
Simulated I/O supported through expansion modules
Communication port -1 x PROFINET (with RJ45 interface)
-1 x PROFIBUS DP master/slave
Communication protocols MPI, PROFIBUS DP, PROFINET IO
Built in real-time clock
Programming languages LAD, FBD, STL, SCL, Graph
The maximum number of modules can be expanded to 32 (with appropriate power supply/expansion rack)
Power supply voltage 24 V DC
Dimensions (width x height x depth) 80 x 125 x 130 mm
Installation method: DIN rail installation
Working temperature 0-60 ° C
