SPHHS03 Hydraulic Servo Module

Model: SPHSS03
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

SPHHS03 Hydraulic Servo Module

Product manual:

Product Features of SPHHS03 Hydraulic Servo Module

SPHHS03 is a servo control module in industrial hydraulic systems, mainly used in precision hydraulic control scenarios to achieve high-precision position, speed, and pressure regulation. Commonly used in mechanical manufacturing, injection molding, stamping, and other high-performance automation equipment.

core functionality
Servo control: Achieve precise position, speed, and pressure control of hydraulic cylinders or motors.
Closed loop regulation: Real time closed-loop control is achieved through feedback signals (position sensors or pressure sensors).
Interface compatibility: It can be linked with electrical control systems or PLCs to achieve automation control.
Fault monitoring: Real time monitoring of pressure, flow rate, and temperature, providing abnormal alarm signals.
Main Features
High precision control: With high precision in position, speed, and pressure adjustment, it meets the requirements of precision machining.
Quick response: The hydraulic action has a short response time, ensuring the dynamic performance of the system.
Strong stability: designed for high load and high pressure working environments, with anti vibration and durability.
Modular design: easy to install, disassemble, and maintain, compatible with different hydraulic systems.
Security protection function: Built in overvoltage, overcurrent, and overtemperature protection to ensure the safety of equipment and operators.
Industrial adaptability: Suitable for harsh working conditions such as high temperature, high humidity, and dust.
Technical parameters (typical)
Working voltage: Depending on the controller, commonly 24 V DC
Control mode: closed-loop servo control (position/speed/pressure)
Maximum working pressure: approximately 210 bar (specific model to be confirmed)
Maximum flow rate: approximately 15-30 L/min (depending on the specific model)
Response time: in milliseconds
Working temperature: 0 ℃~60 ℃
Installation method: Modular base plate or flange installation
