T8461C digital output module

Product manual:

T8461C Digital Output Module Description
Module Role

T8461C is a safety type digital output unit in the HIMA safety system, whose main task is to reliably execute instructions issued by the safety controller to on-site devices. It is a key module in the "execution layer" of the safety system.

It is directly related to whether the equipment can be promptly cut off or reset to a safe state in dangerous situations.

Overview of Working Principle

Security processors (such as T8110/T8151) complete logical judgments

Send the result to T8461C

T8461C drives on-site execution of component actions

If the system detects an exception, the module will force the output to enter a safe state

The entire process is designed with the core principle of 'failure is safety'.

main function

Drive on-site execution mechanism
Control solenoid valves, contactors, relays, shut-off devices, etc

Implement safety actions
Used for critical operations such as emergency parking, energy cut-off, equipment isolation, etc

Ensure output reliability
The output circuit has the ability to detect and diagnose, reducing the risk of misoperation

Module characteristics

Designed for security systems, emphasizing determinism and reliability

Clear output action and short response time

Support online system diagnosis for easy maintenance

Suitable for continuous operation in industrial environments

Common usage scenarios

ESD emergency stop system

Safety cut-off circuit of process equipment

Fire/combustible gas interlock output

The final execution circuit of high-risk equipment

High security projects such as energy, electricity, and petrochemicals

T8461C Product details picture:
