TB852 3BSC950263R1 Terminator Module

Brand:ABB
Model:TB852 3BSC950263R1
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

TB852 3BSC950263R1 Terminator Module

Product manual:

ABB

application
Used in ABB AC800M system as the terminator of RCU (Remote Control Unit) communication link, ensuring the integrity of link communication and preventing signal reflection, commonly found in Profibus or S800 I/O distributed system architecture.

major function
Provide physical layer termination functionality

Usually installed at the end of the communication link

Ensure stable transmission of data bus signals

Applicable system
ABB 800xA DCS control system
ABB S800 I/O System

Installation method
Standard DIN rail installation, simple wiring

Work environment requirements (routine)
Temperature range: 0~55 ° C

Protection level: IP20 (to be installed inside the cabinet)

Application scenarios
Power plant automation

Petrochemical process control

Manufacturing automation system

Various ABB control system on-site terminals
