TEL Tokyo Electron 1181-000826-14 Motor Distribution Board

Product manual:

Introduction to TEL Tokyo Electron 1181-000826-14 Motor Distribution Board
Product definition:
1181-000826-14 is a motor distribution board used in Tokyo electronic semiconductor equipment,
Responsible for the unified distribution and management of control signals and power supply for multiple motors.

Main functions:
Centralize the distribution of control signals such as start, stop, and speed regulation from the main controller,
Coordinate multiple motors to operate synchronously or independently, while supplying power to the motor module.

Applicable device types:
Commonly used in TEL wafer transfer systems, automatic handling devices
In equipment such as gas valve control systems and precision positioning mechanisms, such as CVD, Etch, Coater/Developer, etc.

Supported motor types:
Generally supports stepper motors, servo motors, and small DC motors, with multi-channel control interfaces,
Suitable for multi axis motor systems.

Product features:

Multi channel output, supporting multiple motors to be connected simultaneously

Equipped with status indication and overcurrent/short circuit protection circuit

Clear wiring for easy debugging and maintenance

Strong electromagnetic interference suppression capability, suitable for operation in clean room environments

Installation location:
Usually installed in the equipment main control cabinet or motion control unit, close to the motor drive module and motion axis.

Typical application scenarios:

Wafer lifting mechanism

Wafer transfer arms

Rotating/conveying mechanism inside the process chamber

Mask board movement, clamping and other action systems

Product details picture:

1181-000826-14
