TEL Tokyo Electron 1181-000828-12 Motor Distribution Board

Product manual:

TEL Tokyo Electron 1181-000828-12 Motor Distribution Board - Product Application Fields
1. Multi motor control and distribution
This distribution board is used to manage the power and control signals of multiple motors,
Realize unified scheduling and allocation control of multiple moving parts in the device, such as pumps, fans, sliding tables, rotating motors, etc.

2. Semiconductor equipment driver system
Widely used in TEL's coating and developing machines, cleaning equipment, etching machines, etc,
As the core control interface of the motor drive system, it is used to connect and allocate data from the main control unit
The control signal of (such as a controller or driver).

3. Interface of automation control system
As a part of the equipment automation system, this board supports receiving instructions from the upper computer or PLC,
And distribute it according to the motor channel for execution, while feeding back the motor operating status to the main control system.

4. Fault detection and interlocking control
Capable of real-time monitoring of the operating status of various motors, capable of handling overload, disconnection
Provide feedback on overheating and other situations, and trigger fault interlocking or alarm mechanisms to ensure stable system operation.

5. Equipment maintenance and module replacement
Adopting standardized modular design, it can be used for equipment maintenance and quick replacement, improving maintenance efficiency,
Reducing equipment downtime is one of the important spare parts in semiconductor manufacturing equipment.

Product details picture:
