TEL Tokyo Electron 1208-001151-11 Control Motherboard Card

Brand:TEL Tokyo Electron
Model:1208-001151-11
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

TEL Tokyo Electron 1208-001151-11 Control Motherboard Card

Product manual:

Product model: 1208-001151-11
Manufacturer: Tokyo Electron Ltd. (TEL)
Component Type: Main Control Circuit Board/Mainboard Control Module

1、 Product Overview:
1208-001151-11 is a control motherboard card used in TEL semiconductor equipment,
Its core function is to serve as the central control processing platform for a subsystem or the entire machine in the device.
It undertakes the main logical operations and management tasks including data processing, control instruction execution, signal communication, equipment linkage, etc.

2、 Main functions:
Function module description
The central processing unit integrates an embedded CPU or control chip, responsible for executing control programs
Internal storage with non-volatile Flash memory or SRAM/EEPROM for parameter storage
Peripheral interfaces provide various connection interfaces such as I/O, communication ports, encoders/analog inputs, etc
Bus communication and external module communication (possibly using TEL proprietary communication protocol, RS232, EtherCAT, CAN, etc.)
Control program management loads TEL device control firmware to achieve process scheduling and subsystem synchronization control

3、 Technical parameters (based on commonly used TEL control motherboards):
Project content (possible specifications)
Working voltage 5V/12V/24V DC (supplied according to the system)
Communication port RS-232C, Ethernet, CAN, IO expansion interface
Control signal processing capability supports multi-channel DI/DO, AI/AO, PWM control, etc
Software supports TEL proprietary operating system or real-time embedded firmware
Installation form: plug-in card/backplane connection/screw fixed, installed in TEL control rack

4、 Application device type (speculated):
The 1208-001151-11 control motherboard card may be integrated into the following TEL device control system as its core control logic part:

Lithium/ACT series coating and developing equipment

Unity/Telius series plasma etching system

Trias series CVD/ALD system

Control architecture for transport systems such as EFEM, Transfer Module, Load Port, etc
