TEL Tokyo Electron 1208-001196-11 Sensor Board

Product manual:

The TEL Tokyo Electron 1208-001196-11 Sensor Board is a critical module in semiconductor equipment,
Used to collect and process signals from various sensors, achieve monitoring and control of device status and environmental parameters.

1、 Basic Product Information
Project Content
Model 1208-001196-11
Name: Sensor Board
Manufacturer Tokyo Electron Ltd. (TEL)
Function type: Multi sensor signal acquisition and conditioning module

2、 Core functions
Function category description
Multi channel sensor signal acquisition supports multiple sensor inputs such as temperature, pressure, humidity, etc
Signal conditioning and amplification amplify and filter the analog signals output by sensors
Signal conversion from analog to digital for easy processing by the main control system
Real time collection of environmental and device parameters for status monitoring, supporting alarm function

3、 Typical application areas
Application scenario description
Monitoring key process parameters such as temperature, pressure, and gas flow rate in wafer manufacturing equipment
Vacuum system collects signals from vacuum pressure sensors
Gas supply system monitors gas flow and valve status
The equipment safety interlock system monitors the status of safety sensors such as door switches and leak detection

4、 Technical features
Characteristic Description
High sensitivity, multi-channel input supports multiple types of sensor interfaces, collects multiple signals
Low noise amplification maintains signal accuracy and reduces environmental interference
Industrial grade design resistant to vibration and electromagnetic interference, suitable for clean room environments
Standard interface supports analog and digital signal output, compatible with multiple main control systems

Product details picture:

1208-001196-11
