TEL Tokyo Electron 1880-027845-11 Acquisition Card

Product manual:

TEL Tokyo Electron 1880-027845-11 Data Acquisition Card (DAQ)
It is an industrial grade signal acquisition module used in semiconductor manufacturing equipment,
The main function is to collect and transmit analog or digital signals from subsystems such as sensors, switches, and actuators to the central control system
Implement key control functions such as equipment status monitoring, process feedback, and safety interlocking.

The following is a detailed application area and functional description of the acquisition card (without graphics):

1、 Basic Information
Product model: 1880-027845-11

Product Name: DAQ Module

Manufacturer: Tokyo Electron Ltd. (TEL)

Category: Industrial signal acquisition module/I/O control board

2、 Core functions
Multi channel signal acquisition

Support the collection of multiple analog signals (Analog Input) and digital signals (Digital Input);

Typical collected signals include temperature, voltage, current, pressure, photoelectric status, etc.

Signal Conversion and Processing

Integrated high-precision A/D conversion circuit (such as 12 bit or 16 bit ADC);

Filter, amplify, and convert analog signals to ensure that the control system can directly read them.

Real time data upload

Transfer the collected data to the central control module (such as E244 or BX series);

Realize real-time feedback and processing of device operating status.

Electrical isolation and protection design

The channels are designed with electrical isolation to enhance the anti-interference ability of the equipment;

Provide overcurrent and overvoltage protection to improve system stability and reliability.

Product details picture:
